NXP3220

Overview.

High performance Multimedia 32bit Quad core Application Processor

NXP3220 is a system-on-a-chip (SoC) based on the 32-bit RISC processor for Smart devices, Designed with the 28 nm low power process, features of NXP3220 includes :

NXP4330Q is a system-on-a-chip (SoC) based on the 32-bit RISC processor for tablets and cell-phones. Designed with the 28 nm low power process, features of NXP4330Q include:

  • • Cortex-A7 Dual core CPU
  • • Highest memory bandwidth
  • • Full HD display
  • • 1080p 60 frame video decoding hardware
  • • High-speed interfaces such as eMMC4.5 and USB 2.0

NXP3220 uses the Cortex-A7 Dual-cores, which are based on the ARMv7-A architecture and deliver more single thread performance than the Cortex-A5 and incorporates all features of the high-performance Cortex-A15 and Cortex-A17 processors, including virtualization support in hardware, Large Physical Address Extensions (LPAE), NEON, and 128-bit AMBA 4 AXI bus interface. It provides 5 GB/s memory bandwidth for heavy traffic operations such as 1080p video decoding, high resolution image signal processing with Full HD display.

Diagram.

NXP3220 Block diagram

Features.

CPU

  • • Cortex-A9 Quad Core @ 1.4Ghz w/ 32Kbyte I-Cache, 32Kbyte D-Cache per core
  • • 1MByte L2 Cache
  • • VFP(Vector float-point Processor), Neon Processor per core

System Controller

  • • 32 channels DMA, Interrupt Controller
  • • Clock & Power management for Normal, Idle, Stop and suspend to RAM (Deep Sleep)
  • • 4 channels Timer/Watchdog Timer
  • • RTC

Memory/Storage Controller

  • • System Memory : Supports LPDDR2/3 and DDR2/3 up to 4Gbytes @ 933Mhz(T.B.D)
  • • SRAM, ROM and NOR flash controller
  • • SLC/MLC NAND Flash Controller w/ up to 60bit ECC
  • • Supports 3 independent SD/MMC/eMMC controller

FHD Multi-format video codec

  • • FHD Multi-format video decoder
  • • FHD H.264 video encoder

3D Graphic

  • • Enhanced 3D graphic processor
  • • Supports OpenGL|ES 1.1/2.0, Open VG

Display Controller & Video Post-processor

  • • Supports Multiple display up to 2 separate devices 1920x1280@60hz
  • • Supports 24bit RGB, i80 I/F, LVDS, HDMI 1.4a w/HDCP 1.4 compliant, MIPI-DSI
  • • Supports 3D De-interlace, Fine video scalar and Color space converter

Video Input Processor

  • • Supports x3 8bit BT656/601 format
  • • Supports MIPI-CSI2

Connectivity

  • • Supports Gigabit Ethernet MAC
  • • Supports the latest USB 2.0 HSIC, USB 2.0 Host and USB 2.0 OTG
  • • Supports MPEG-TS parser with DVB-CSA for TV application

Peripherals

  • • 6x UART, 3x SPI, PPM, 3x I2C, 3x PWM, 2x MPEG-TS
  • • 3x I2S, SPDIF Rx/Tx, 2x PDM for glueless interface w/ Digital MIC
  • • 8x 12bit general purpose ADC

Security

  • • ARM TrustZone : TZPC, TZASC and TZMA
  • • Hardware crypto accelerator : DES/TDES, AES, SHA, MD5 and PRNG
  • • Supports Secure boot and Secure JTAG

Package

  • • 17x17mm body size, 513 FCBGA, 0.65mm pitch
